10X 5.0MP IP 80M IR Motorized Zoom Camera
- 1/2.8" Low Illuminance 5MP CMOS Sensor
- 5MP / 1920P Frame Rate
- 5-50mm 10X Motorized Auto Focus ICR Optical Zoom Lens
Description
| CB-10X-1580 | |
| Sensor | 1/2.8" Low Illuminance 5MP CMOS Sensor (MStar SSC30KD + SONY IMX 335) |
| Frame Rate | 5MP / 1920P (2592*1944)@30fps, 4MP/3MP/2MP/720P@30fps |
| Minimum Illumination | Color: 0.01 Lux @ F1.2(AGC ON), B/W: 0Lux @ F1.2(AGC ON) |
| Lens | 5-50mm 10X Motorized Auto Focus ICR Optical Zoom Lens |
| Iris Control Mode | Fixed |
| Focus Mode | Auto / Semi-Auto / Manual |
| Electronics Shutter | AES / 1/25S - 1/10,000S, Support Day and Night Electronic Shutter Adjustment |
| Gain Control | AGC |
| White Balance | AWB (Auto / Manual / Lock) |
| BLC | BLC: On/Off |
| Aperture Value | Manual / Auto (F1.6 ~ F2.8) |
| View of Angle | H: WIDE 51.8°, TELE 5.86° V: WIDE 39.1°, TELE 4.4° |
| Close-Up Distance | 1.5-80 Meter |
| Day / Night * | Auto / Dual IR-Cut filter |
| Auto Control IR LED | PWM |
| Ambient Light Detection | IR Illumination on 1-15 Grades Adjustable |
| IR Range | 6pcs 42 MIL Array IR, IR Distance: 80M |
| IR Mode | Standard / Face without Exposure / license Plate |
| DNR | 2D + 3D DNR |
| HDR / WDR | Support HDR & DWDR |
| Smart Image Enhance | Strong Light Suppression, Face Overexposure Prevention, Smart Infrared |
| S/N Ratio | More than 60 dB |
| Video Encoding | H.265 +, H.265 Main Profile / H.264 High Profile / H.264 Main Profile / H.264 Baseline Profile |
| Video Compression | H.265 / H.264 / M-JPEG / MPEG-4 |
| Max Resolution | Main Stream: 2592*1944@25/30fps 2560*1440/2304*1296/1920*1080/1280*720@25/30fps Sub Stream: 1280*720 / 800*448 / 640*480 / 352*288@@25/30fps |
| Bit Rate | 32Kbps ~ 10Mpbs VBR / CBR |
| Smart Code | Smart H.265 / H.264, Dynamic Code Stream, Fixed Code Stream, Low Code Stream |
| Audio Encoding | G/711 / G.711A(64Kbps) |
| Audio | 1 Audio Input / 1 Audio Output |
| LAN Ports | RJ45*1, 10Base-T /100Base-TX |
| Network Protocol | DDNS, DNS, DHCP, FTP, HTTP, HTTPS, IPv4, IPV6, NTP, PPPoE, RTCP, RTP, RTMP, RTSP, SNMP, SMTP, TCP/IP, UPNP |
| Protocol | ONVIF2.4 / CGI / HIKVISION |
| Communication Protocol | Pelco-D, Pelco-P |
| Baud Rate | 1200 / 2400 / 4800 / 9600bps (Default: 115200bps) |
| Software Control | IE, CMS |
| Browser | Windows XP/7/10, IE8+ , Chrome31+, Firefox30+, Safari8.0+ |
| Mobile View | Support Windows, Symbian, iPhone Platform Smart phone |
| Mobile App | Support P2P |
| Preview Videos | Max. 3 Users Preview at the same time |
| Storage | Support 256GB Micro SD Card Storage and Support Scheduled Video Storage |
| Reset Button | Built-in Reset Button*1, External Reset Button*1 |
| Snapshot | Remote Timing Snapshot, Mobile View Images Snapshot |
| Motion Detection | Intelligent Multiple Detection Zones (Max. 4 Zones, Sensitivity 1-100 level) |
| Humanoid Detection | Humanoid Detection Record, Snapshot, Alarm Output, Tracking |
| Alarm Linkage | E-mail Alert and Upload Snapshot to FTP, Relay Out, Mobile Phone App |
| Smart Detection | Humanoid Detection, Area Intrusion Detection, Cross Border Detection, Entering Area Detection, Fast Motion Detection, Motion Detection, Video Occlusion Detection |
| Smart Recording | Motion Detection Recording, Humanoid Detection Recording, Timing Recording |
| Proportional Zoom | Support |
| Privacy Mask | Support, Up to 4 Areas |
| Operation Menu | Multiple Languages for OSD Menu |
| Text Overlay | Channel Name, date & Time |
| Recording Mode | SD Card, Computer, Browser, P2P Client Software, NVR |
| Operating Temp. | Indoor: 0° - 40°, Outdoor: -40° - 65℃ |
| Humidity | ≤95% Non Condensing |
| Power | 220±10%VAC & 50Hz.12VDC/24VDC ≤2A |
| Power Consumption | ≤ 10W |
| Lighting Protection | Transient Voltage 6000V, Anti-Surge |
| Weight | 0.8KG (N.W.) / 1.2KG (G.W) |
| Related Validation | IP66 |
| Certification | CE / FCC / RoHS |
