HDMI over Coax Extender
- Send HDMI signal over single coaxial cable up to 100M at 1080p solution
- Support HDMI 7.1 Channel audio
- Option model: HE01CR Receiver
Description
| HE01CT | HE01CR | |
| Video Resolution | 480i, 576i, 720p@50/59.94/60Hz, 1080i@50/59.94/60Hz, 1080p@23.98/24/29.97/30/50/59.94/60Hz | |
| Audio Support | LPCM 7.1 Channels, 48Khz, 16 / 20 / 24Bit | |
| HDMI Connector | HDMI Type A | |
| SDI Connector | BNC 75 Ohm | |
| Power Consumption | 850mA (Max) | 750mA (Max) |
| Power Supply | Switching DC 5V / 1AMP | |
| Temperature | Operation: 0 ~ 55°C , Storage: -20 ~ 85°C, Humidity: up to 95% | |
| Dimension | 67 x 110 x 27 mm | |
| Weight | 200g | 200g |
| Certification | CE / FCC / RoHS | |
